Explore the Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
Crank Preload Ring
  • 7075 aluminium
  • anodised finish
  • maximise bottom bracket bearings lifespan

Crank Preload Ring

SKU Code: 20789
£25.00

The Muc-Off Crank Preload Ring is a super durable, precision CNC machined 7075 piece of hardware. It allows you to precisely adjust the ‘preload’ tension on the bottom bracket bearings. What does this do? It helps to remove the side-to-side play and slack in thru-spindle bottom brackets, to help maximise the life of your bottom bracket bearing, as well as giving you a creak-free ride. Read more

  • available in 12 colours
  • precisely adjust the ‘preload’ tension
  • Free UK delivery over £30
    Free UK delivery over £30
  • Fast UK Fedex delivery (1-3 days)
    Fast UK Fedex delivery (1-3 days)

Pairs great with:

  • Bio Grease - 150g

    Bio Grease - 150g

    Pedals, Bearings, Metal Seatposts and Cables lets get Greasy!

    £23.00

SEE IT IN ACTION

Crank Play Go Away! Precisely adjust the ‘preload’ tension on the bottom bracket bearings helping to remove the side-to-side play and slack in thru-spindle bottom brackets. This will help to maximise the life of your bottom bracket bearing, as well as giving you a creak-free ride. Take a closer looks as our in-house certified bike nerd Chopper takes you through how to install the Muc-Off Crank Preload Ring.

HIGHLIGHTS

  • Precision CNC machined, 7075 aluminium body and threaded adapter ring for a perfect fit
  • Stainless steel hardware
  • Available in 12 anodised colours

  • Description

    The Muc-Off Crank Preload Ring is a super durable, precision CNC machined 7075 piece of hardware.

    It allows you to precisely adjust the ‘preload’ tension on the bottom bracket bearings. What does this do? It helps to remove the side-to-side play and slack in thru-spindle bottom brackets, to help maximise the life of your bottom bracket bearing, as well as giving you a creak-free ride. It also comes in our classic anodised colours for added bling!

    It fits onto the left crank arm of any mountain, gravel or road bikes that have SRAM, RaceFace or Easton 30mm spindle cranks, or SRAM DUB 28.99mm spindles installed.

  • PRODUCT COMPATIBILITY

    Our precision crank pre-load ring fits onto the left crank arm of:

    • Mountain bikes
    • Gravel bikes
    • Road bikes

    that have:

    • SRAM 30mm spindle cranks
    • Race Face 30mm spindle crank
    • Easton 30mm spindle cranks
    • SRAM DUB 28.99mm Spindles installed
    • UNITE 30mm spindle cranks

  • FEATURES

    • Precision CNC machined, 7075 aluminium body and threaded adapter ring for a perfect fit
    • Stainless steel hardware
    • Allows you to precisely adjust the preload tension on the bottom bracket to help extend the life of your bb bearing!

  • HOW TO



    SRAM 30MM SPINDLES

    Tools required: Alongside your usual bike tools required to remove your cranks, you’ll also need a bottle of thread lock (Loctite 638 or similar).

    1. Place the bike in a bike stand.
    2. Either remove the chain completely or remove it from the front chainring.
    3. Remove the entire crankset according to manufactures instructions.Loosen the bolt on the OEM crank ring with an appropriately sizedtool.
    4. Turn the ring clockwise one full turn.
    5. Tighten the bolt.
    6. Pull on the crank ring to remove the entire assembly, including thespacer ring.
    7. Place the OEM crank ring to one side, this will not be reused.
    8. Clean the crank spindle thoroughly using Muc-Off Bio Degreaser.
    9. Unbox the ‘Muc-Off Crank Pre-Load Ring’.
    10. Slide the appropriate Muc-Off spacer ring onto the crank spindle.
    11. Check you have the correct size installed, it should be a tight fit, the spacer ring should not wobble.
    12. Remove the spacer ring and apply a small amount of thread lock to the area of the spindle where the spacer ring will be located.
    13. Slide the spacer ring back onto the spindle.
    14. Wipe away any excess thread lock - Avoid getting any onto thethreads.
    15. Rotate the spacer half a turn to ensure good thread lock coverage
    16. Leave the thread lock to set for 24 hours.
    17. Screw the Pre-Load Ring onto the spacer until it’s finger tight.
    18. Reinstall the crankset onto the bike.
    19. Unscrew the Preload Ring following the directional arrows, until ittouches the bottom bracket bearing.This does not need to be tight,just enough to stop the crankset frommoving.
    20. Tighten the stainless bolt to 1Nm torque with a 2mm Hex Key.
    21. Give the cranks a spin to ensure everything is moving smoothly. Ifthere is too much resistance, loosen the bolt and back off the Preload Ring slightly.

    Periodically spray a protectant such as HCB-1, MO-94 or Bike Spray onto body to ensure there is zero corrosion.

    RACEFACE®

    Tools required: Alongside your bike tools to remove your cranks you will also require a bottle of thread lock (Loctite 638 or similar)

    1. Place the bike in a bike stand
    2. Either remove the chain completely or remove it from the front chainring.
    3. Remove the entire crankset according to manufacture instructions. Loosen the bolt on the Raceface crank ring with an appropriately sized tool.
    4. Unscrew the existing Raceface preload ring and remove it from the spindle.
    5. Place the OEM crank ring to one side, this will not be reused.
    6. Clean the crank spindle thoroughly using Muc-Off Bio Degreaser.
    7. Unbox the Muc-Off Crank Preload Ring.
    8. Screw the Preload ring onto the spacer until it is finger tight. (You will not need a spacer ring.)
    9. Reinstall the crankset to the bike.
    10. Unscrew the Preload Ring in the direction the arrows shows until it touches the bottom bracket bearing. This does not need to be tight, just enough to stop the crankset from moving.
    11. Tighten the stainless bolt to 1Nm torque with a 2mm Hex Key
    12. Give the cranks a spin to ensure everything is moving smoothly. If there is too much resistance, loosen the bolt and back off the Preload Ring slightly. RACE FACE® is a registered trademark. SRAM™ is a registered trademark.

    Periodically spray a protectant such as HCB-1, MO-94 or Bike Spray onto body to ensure there is zero corrosion.

  • PROJECT GREEN

    Project Green is our never-ending commitment to deliver a multitude of environmentally-focussed improvements across our business. We love the planet we ride on, it’s our playground, and we’re driven to protect it for everyone.

    This product has a Project Green credential; meaning that it’s either biodegradable, refillable, reusable, or all three!

    What are the Project Green Credentials of the Crank Pre-Load Ring?

    The product is designed to last a lifetime of use and can be moved from one bike to another. No plastics are part of its construction with all packaging being cardboard.

  • Frequently Asked Questions

    How do I know if it fits my bike and why cannot I see a list of bikes that these fit?

    Not every bike manufacturer uses the same model of components across their entire range of bikes every year, so a list of compatible bike models would be near impossible to create. It is easy to read the bike spec or by looking at the bike to see the model of cranks are fitted and if they are compatible to fit one of these.

    Why does it not fit all cranks?

    With so many different cranks and bottom brackets available in the marketplace many different standards exist. This is designed to fit as many models as possible with as few extra attachment spacers as possible included so not to create extra waste so not to ship each not with multiple fitment attachments.

    How is this product sustainable?

    The product is designed to last a lifetime of use and canbe moved from one bike to another. No plastics are part of its construction with all packaging being cardboard.

    Which glue do I need to use for the thread lock?

    We recommend using Loctite 638 but any glue with similar adhesion is suitable.

  • What's Included

  • Reviews

    Trustpilot

  • Super durable, precision CNC machined 7075 Aluminium

    Maximise the life of your bottom bracket bearing, as well as giving you a squeak-free ride with this hard as nails bit of componentry.

  • Add some bling to your ride

    With 12 vibrant anodised colours to choose from, make your ride unique & stand out from the pack - without the creaks!
